Home > Incoloy Alloy Pipes & TubesIncoloy Alloy 800 Pipes & Tubes
Material Description
UNS N08800
Chemical Composition, %
Ni
Fe
Cr
Cu
Ti
Al
C
Mn
S
Si
30.0-35.0
39.5 min
19.0-23.0
.75 max
.15-.60
.15-.60
.1 max
1.5 max
.015 max
1.0 max
Incoloy alloy 800 is nickel-iron-chromium alloys with good strength and
excellent resistance to oxidation and carburization in high-temperature
exposure. Incoloy alloy 800 was the first of these alloys and it was
slightly modified into Incoloy 800H. This modification was to control
carbon (.05-.10%) and grain size to optimize stress rupture properties.
The nickel content makes the alloys highly resistant to both chloride
stress-corrosion cracking and to embrittlement from precipitation of
sigma phase. The general corrosion resistance is excellent. In the
solution annealed condition.
Incoloy 800 is primarily used in applications with temperatures up to
1100° F. The chemical balance allows the nickel steel alloy to exhibit
excellent resistance to carburization, oxidation and nitriding
atmospheres.
Characteristics
● High temperature strength
● High creep rupture strength
● Resistant to oxidation and carburization in high temperature environments
● Good corrosion resistance in many acidic environments
● Good resistance to many sulfur-containing atmospheres
Application
● Ethylene furnace quench boilers
● Hydrocarbon cracking
● Valves, fittings and other components exposed to corrosive attack from 1100-1800° F
● Industrial furnaces
● Heat-treating equipment
● Chemical and petrochemical processing
● Super-heater tubing and re-heater tubing in power plants
● Pressure vessels
● Heat exchanger tubing
Seamless Tube Information:
Specification: ASTM B-163 / ASME SB-163, ASTM B-407 / ASME SB-407
Outside Diameter: 6.0-114 mm
Wall Thickness: 0.5-15 mm
Length: Max.24000mm (the maximum length is for the scope of special diameters and walls)
Other sizes are on the request
